Lite Series
LB55G-2
- VAP450 (Vestel Android Platform 450)
- 2 GB DDR4 / 16 GB eMMC
- Resolution : 3840 x 2160 (16:9) – UHD
- Brightness : 350 cd/m2
- Operation : 16/7
- Interface : HDMI 2.0 / USB / RS232 / RJ45 / Speaker
- Application Area: Retail, Hospitality
Panel
Screen Size55"
Panel TechnologyIPS
Backlight TypeDLED
Brightness (typical)350 cd/m²
Native Resolution3840 x 2160 (16:9) – UHD
Contrast Ratio (typical)1200:1
Dynamic Contrast Ratio50000:1
Panel Life Time ( Min. )30000 Hrs
Response Time (typical)8 ms
Active Area (H x V)1209.6 x 680.4 mm
Viewing Angle178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Color Value1.07 G (8 bits + FRC)
Color Gamut68% NTSC
Haze Level1%
Refresh Rate60 Hz
OrientationLandscape
Operation Hours16/7
Area of UsageIndoor
Built-in System
Mainboard Model17MB450VS
Operating SystemCustom OS (built on Android AOSP)
Memory2 GB DDR4
Storage16 GB eMMC
CPUQuad-Core ARM Cortex-A55
GPUARM Mali-G31 MP2
Wired10/100/1000 Mbps Ethernet, IEEE 802.1X Authentication
WiFiWiFi 5 (802.11 a/b/g/n/ac), IEEE 802.1X Authentication
BluetoothBT 5.1
HTML5 BrowserVewd
Wireless DisplayMiracast
Monitor Connectivity
Video Input2xHDMI2.0
External Control1x RJ45 LAN (Gigabit Ethernet), 1x RJ12 (For Service), 1x RS232 (3.5 mm jack)
USB1xUSB-A 3.0, 1xUSB-A 2.0
Mechanical
Product Dimensions (WxDxH)1233 x 66 x 712 mm
Package Dimensions (WxDxH)1369 x 154 x 860 mm
Product Weight13.2kg
Package Weight17.9kg
Vesa Mounting200 (V) x 200 (H) mm M6
Bezel WidthB: 15 mm, T/L/R: 3 mm
Environmental Conditions
Operating Temperature0-40°C
Operating Humidity10-80%
Power
Power Supply110 VAC – 240 VAC – 50/60 Hz
Power Consumption
Typical77 W
Maximum140 W
Deep Standby≤0.5 W
Features
Main FeaturesWireless Display, Vewd HTML5 Browser, Open Content Management Support, VsignLite Player, Media Player, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock, RCU Inhibit, NoSignal Power Off, Pixel shift, Remote control via LAN, Real Time Clock
Mechanical FeaturesEmbedded IR, Rocker Switch, Detachable Power Cord
Speaker2×10 W
Accessory
StandardQSG, IB, Power cord, Remote control unit, RC battery
Certification
SafetyYes
EMCYes
CEYes
