EL32C-1D
- Resolution : 1920×1080 (FHD)
- Brightness : 450 cd/m2
- Operation : 24/7
- Bezel : 21-25 mm (T/R/L), 13-16 mm (B)
- Interface : HDMI 2.0 / DP 1.2A / USB /RS232 / RJ45 / Audio / Speaker
- Application Area: Retail
Panel
Screen Size32"
Panel TechnologyFSA (VA)
Backlight TypeDirect-Type LED
Brightness (typical)450 cd/m²
Native Resolution1920 x 1080 (16:9) – FHD
Contrast Ratio (typical)3000:1
Dynamic Contrast Ratio45000:1
Response Time (typical)9.5 ms
Active Area (H x V)698.40 x 392.85 mm
Viewing Angle178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Color Value16.7M
Screen Treatment3H
Haze Level0,03
Refresh Rate60 Hz
OrientationLandscape/Portrait
Operation Hours24/7
Area of UsageIndoor
Built-in System
Mainboard Model17MB130VS
Operating SystemLinux (HTML5 based app support)
Wired10/100 Mbps
WiFiWiFi 4 (802.11 a/b/g/n)
BluetoothNA
Monitor Connectivity
RGB InputN/A
RGB OutputN/A
Video Input1xHDMI2.0, 2xUSB2.0, DP1.2a
Video OutputDP1.2a
Audio InputN/A
Audio OutputHeadphone
External ControlRS232(DE-9F), Ethernet(RJ45), Service(RJ12)
External SensorRJ12
Mechanical
Product Dimensions (WxDxH)734 x 78 x 435 mm
Package Dimensions (WxDxH)795 x 128 x 530 mm
Product WeightTBD
Package WeightTBD
Vesa Mounting75 x 75 mm M4
Bezel WidthB:21 | T/ L/R:14 mm
Environmental Conditions
Operating Temperature0-40°C
Operating Humidity10-90%
Power
Power Supply170 VAC – 240 VAC – 50/60 Hz
Power Consumption
Typical42 W
Maximum65 W
Deep Standby≤0.5 W
Features
Mechanical FeaturesJoystick, IR Extender or Embedded IR Support Options, Rocker Switch, Detachable power cable(Class 2), Logo on bezel only horizontal
Speaker2 x 6 W
Certification
SafetyYES
EMCYES
CEYES
